Base Profile - Fascia Mount - Easy Glass Prime Balustrade

Aluminium Base Shoe - 2500mm and 5000mm Lengths for Fascia Mounted Glass Balustrade

Easy Glass Prime Fascia Base Shoes are designed to use the ingenious adjustable Q-Disc mounting system which is the quickest glass installation and glass adjustment system ever.

Base Profile - Fascia Mount - Easy Glass Prime

Options Length
(mm)
Fixing Hole
(mm)
X
(mm)
Material Code Price (inc VAT) Quantity
2500mm 2500 16 50 Aluminium 16.6961.000.18 £430.38
3-5 days
5000mm 5000 16 100 Aluminium 16.6961.500.18 £860.82
3-5 days

Key Features:

Aluminium Manufactured from aluminium.
Brushed Finish Brushed satin finish.
Q-Disc System Uses adjustable Q-Disc system for glass installation.
Choice of Fixings Available Choice of high performance anchor bolts available

Fascia glass balustrade base shoes in a choice of 2500mm and 5000mm lengths, suitable for cutting to size.

Pre-drilled with 16mm diameter holes for fixing.

Supplied with connection pins for perfect alignment with corner and additional base profiles.

Manufactured from aluminium with brushed finish.

Suitable for interior or exterior applications.

A choice of various base-shoe fixing methods (mechanical anchors, stud anchors and even threaded rods).

Secures glass thickness of 16.76mm - 21.52mm when combined with Q-Disc System.

Designed for light to heavy usage.

Base Profile Dimensions:

Height: 140mm

Width: 73mm

Bore Mounting Side: 16mm

Mounting Advice

Any quoted figures about the performance of these products relate to installing into concrete.

Please take advice from an engineer or specialist when installing into any other material, such as timber.


Please Note:

United Kingdom Delivery Lengths over 2.5 metres will attract a delivery surcharge of 40.00 inc VAT.
This applies to the United Kingdom only.
International Delivery Lengths over 1.8 metres are not eligible for international delivery.
Please contact us by phone or email and we will try and find you the best solution.

Installation Advice

Need some help?

Download and print our installation advice sheet for Fascia Mount Easy Glass Prime Balustrade.

Fascia Mount Frameless Pro Glass Balustrade Installation Fascia Mount Frameless Pro Glass Balustrade Installation Fascia Mount Frameless Pro Glass Balustrade Installation

Choice of base shoe fixings available

Tip: Always use 316 grade stainless steel fixings for external installations, we would only recommend using zinc-plated fixings for internal installations.

United Kingdom Delivery

12mm x 85mm - Anchor Bolt - Hexagon Head.

International Delivery

M12 x 94mm Anchor - Allen Head Bolt.

International Delivery

M12 x 175mm Threaded Stud Anchor.
